Item Description
Description: Clear PVC Food and Beverage Grade Vacuum Transfer hose
Tube Compound: Clear Food Grade PVC
Reinforcement: Spiraled Wire Helix
Vacuum Rating: All Sizes rated at 28" Hg
Temp. Range: +15 to +150F / -10 to +65C *
Applications: A "See Through" flexible hose for use where full vacuum or collapse resistance is required. Suitable for use with most foodstuffs, cosmetics, beverages, lubricating oils, animal fats, and a wide range of chemicals. Suitable for wine suction and discharge.
Temp. Range: +15 to +150F / -10 to +65C *
Applications: A "See Through" flexible hose for use where full vacuum or collapse resistance is required. Suitable for use with most foodstuffs, cosmetics, beverages, lubricating oils, animal fats, and a wide range of chemicals. Suitable for wine suction and discharge.
| Dash | ID | OD | Working Pressure | Weight | |
| Size | Inch | Inch | PSI | lb/ft | |
| -6 | 3/8 | .630 | 101.5 | .11 | |
| -8 | 1/2 | .708 | 101.5 | .12 | |
| -10 | 5/8 | .866 | 101.5 | .17 | |
| -12 | 3/4 | 1.024 | 101.5 | .24 | |
| -16 | 1 | 1.260 | 72.5 | .35 | |
| -20 | 1-1/4 | 1.575 | 72.5 | .44 | |
| -24 | 1-1/2 | 1.850 | 58 | .54 | |
| -32 | 2 | 2.340 | 58 | .85 | |
| -48 | 3 | 3.500 | 45 | 1.49 |
Buy Wire-Reinforced Clear PVC Hoses
The PVC wire vacuum hose is a flexible but tough hose that is a great solution for applications where a strong collapse resistance is required to transfer air or liquid materials. This hose is wire-reinforced and composed of clear food-grade PVC, so you’ll often find it in use in the food and beverage industry as well as some chemical applications. Our wide range of options includes various diameter and length combinations so you’ll be able to select your working PSI rating and approximate weight. Shop for your PVC wire-reinforced vacuum hose with Hose and Fitting Supply today.
