Item Description
Tube: Oil resistant Synthetic Rubber
Reinforcement: 1W/B braid of High Tensile Steel Wire
Cover: Oil, weather and abrasion resistant Synthetic Rubber
Applications: Petroleum base hydraulic fluids and lubrication oils,
Water, Water/ Glycol and Water/ Oil emulsion, Hydraulic Fluids
Use with: Braided Hose Crimp Fittings
R1-1/4: ~350'
R1-3/8: ~350'
R1-1/2: ~350'
R1-3/4: ~350'
R1-1: ~145'
Reinforcement: 1W/B braid of High Tensile Steel Wire
Cover: Oil, weather and abrasion resistant Synthetic Rubber
Applications: Petroleum base hydraulic fluids and lubrication oils,
Water, Water/ Glycol and Water/ Oil emulsion, Hydraulic Fluids
Use with: Braided Hose Crimp Fittings
Interchanges with:
- Weatherhead H104
- Aeroquip FC211
- Parker 421
R1-1/4: ~350'
R1-3/8: ~350'
R1-1/2: ~350'
R1-3/4: ~350'
R1-1: ~145'
| Dash | ID | OD | Working Pressure | Burst Pressure | Min. B/Radius | Weight |
| Size | Inch | Inch | PSI | PSI | Inch | lb/ft |
| -4 | 1/4 | 0.555 | 3263 | 13053 | 3.94 | .15 |
| -6 | 3/8 | 0.713 | 2611 | 10442 | 5.12 | .23 |
| -8 | 1/2 | 0.846 | 2321 | 9282 | 7.09 | .28 |
| -12 | 3/4 | 1.126 | 1523 | 6091 | 9.45 | .42 |
| -16 | 1 | 1.441 | 1262 | 5221 | 11.81 | .59 |
