SAE 100R16

Use with: Braided Hose Crimp Fittings
Tube: Oil resistant Synthetic Rubber
Reinforcement: 2W/B braids of High Tensile Steel Wire
Cover: Oil, weather and abrasion resistant Synthetic Rubber
Applications: Petroleum base hydraulic fluids and lubrication oils,
Water, Water/ Glycol and Water/ Oil emulsion, Hydraulic Fluids

Coil Length:
R16-1/4: ~350'
R16-3/8: ~350'
R16-1/2: ~350'
R16-3/4: ~175'
R16-1: ~175'

Dash	ID	OD	Working Pressure	Burst Pressure	Min. B/Radius	Weight
Size	Inch	Inch	PSI	PSI	Inch	lb/ft
-4	1/4	0.571	5800	23200	1.97	.19
-6	3/8	0.740	4786	19100	2.48	.29
-8	1/2	0.866	3988	15900	3.46	.35
-10	5/8	1.000	3626	14500	3.94	.40
-12	3/4	1.142	3118	12500	4.72	.52
-16	1	1.441	2393	9500	5.91	.73

If you need a hydraulic hose that can handle high pressure, then take a look at the SAE 100R16. This Hose has the same specs as the 100R2 Hose, but it is more flexible. Ideal when looking to upgrade from 100R2 at a fraction of the price. Made from oil-resistant rubber and reinforced with twin bands of high-tensile steel wire, this hose can handle a wide range of fluids, including oils, lubricants, water and other hydraulic fluids. This rubber hydraulic hose has a small bending radius, making it ideal for use in narrow installation spaces. The outer cover is wrapped in synthetic rubber designed to resist cutting, oils, abrasion, corrosion and wear caused by the weather. It can handle extreme temperatures from -40C to +100C without issue, and stand the test of time with a thick sunlight- and aging-resistant cover. For a versatile and reliable hose that can handle high pressure, turn to the SAE 100R16 hydraulic hose.
